SHANGHAI
CMIC
CMIC
1)PVC Rigid Sheet/PVC Decoration Sheet/ PVC ImitationMarble Board Extrusion Line
PVC Transparent Rigid Sheet: Medicine/Gift/Stationery packaging, LED diffuser plate;
PVC Wood-Plastic plate: Decorative panels, door panels, widely used in the building decoration industry;
PVC Imitation Marble Board:
1) The surface of the board is covered with imitation marble pattern, or heat transfer imitation marble pattern and UV curing treatment, good scratch resistance.
2)Board with a variety of colors, it’s convenient to construct.
3)Replace the natural stone such as marble in the interior wall decoration, good aging resistance, UV resistance, yellowing resistance, green environmental protection, no radiation.
Parameters of extrusion line
| Species | Transparent Sheet | Wood-Plastic Board | imitation Marble Board | PVC Decoration sheet |
| Model | SJZ80/156 | JSJZ80/156 | SJZ80/156 | SJZ92/188 |
| Material | PVC | PVC | PVC | PVC |
| Products Width(mm) | 1220 | 1220 | 1220 | 2000 |
| Products Thickness(mm) | 0.5-3 | 1.5-3 | 4-5 | 1.5-6 |
| Output (kg/h) | 400 | 450 | 600 | 600-700 |
2)SPC Composite Floor Production Line
SPC composite floor extrudes by PVC’S base material get through four-roll calender machines, and PVC color film + PVC wearing layer + PVC basis of the membrane, next press and paste these films to be products, simple process, complete the paste that depends on heat, there is no glue.
SPC composite floor production line advantage
1. Waterproof and moistureproof, can fundamentally solve the wooden product problems like easily be rotted and dilated deformation after absorbing water or affected with the wet environment. Therefore, our company ‘s WPC floor can be used in this kind of environment in which the traditional wood product cannot.
2. Colorful, many colors are optional. There are natural wooden feelings and wooden texture, and also you can choose the color you need according to your personality.
3. Environmental protection, no- pollution, pollution-free, recycle. The products do not contain benzene and formaldehyde, it’s an environ-mental product, recyclability reduce the usage of wood, and that is suitable for the sustainable development of national policy and it also benefits society
4.Good fireproofing. it can stop fire effectively, fire rating reaches level B1, when the fire touch products, the fire will put out immediately, and do not produce any toxic
gas.
5. Easy for installation, convenient for wok, simple construction ways, save installed time and fees.
6.Not cracking, not expand, not out of shape, do not repair and maintain, easy to clean, save after-repair and after-maintain fees
Main Technical Specification
| Model | 80/156 | 92/188 | 110/220 |
| Product Width | 1050 | 1220 | 1220 |
| Product Thickness | 3-8 | 3-8 | 3-8 |
| Capacity | 400-500kg/h | 800-1000kg/h | 1200-1400kg/h |
| Main motor power | 75kW | 100kW | 160kW |
3)LVT Composite Floor Production Line
LVT soft composite floor production line, production line by extruder extrusion floor base material, then through a set of six roller for base material and printing layer composite machine, wear-resisting layer, layer of compound at the same time, through the rolling tension, wear-resisting layer accurate control of preheating, to put the volume not wrinkle, does not shrink, deformation, extrusion compound high production efficiency, product quality is stable.
Main technical specification
| Model | SJZ80/156 |
| Material | PVC |
| Products width | 1200mm |
| Products thickness | 1.5-4mm |
| Extruder specification | SJZ80/156 |
| Roller Specification | Ø400 |
| No of rolls | 6PS |
| Capacity(Max.) | 500kg/h |
| Main motor power | 75kW |
4)PVC Semi-skinning(WPC) Foam Board, Co-Extrusion Foam Board
PVC foam board also named Snowboard and Andy board, the chemical component is polyvinyl chloride, also can be named foam polyvinyl chloride board.
PVC Semi-Skinning foam manufacturing technique combines free foam technique and semi-skinning foam to develop new technology, this equipment has advanced structure、simple formulation、easy operation, etc. features.
The feature of PVC Semi-Skinning foam board
1.)Waterproof、anti-flame、anti-acid& akali、anti-moth、light weight、heat preservation、sound insulation、shock absorption
2.)The process the same as wood, but manufacturing performance is much better than wood.
3.)Ideal substitute for wood、aluminum、composite board.
Main technical specification
| Model | Semi-skinning foaming board extrusion line | Core foaming board extrusion line | ||
| Production width | 1220mm | 1560mm | 2050mm | 1220mm |
| Production thickness | 3-40mm | 8-18mm | 8-15mm | 3-40mm |
| Extruder model | SJZ80/156 | SJZ92/188 | SJZ92/188 | SJZ80/156+SJZ65/132 |
| Capacity (Max.) | 400kg/h | 550kg/h | 550kg/h | 500kg/h |
| Main motor power | 75kW | 132kW | 132kW | 75kW+37kW |
